Angelcare Canada AC117B Baby Monitor User Manual

Angelcare Monitors Inc. Baby Monitor Users Manual

Users Manual

OWNER’S MANUAL
Model AC115
Baby Sound and Movement Monitor
AC117
TABLE OF CONTENTS
WARNINGS ..................................................................................................................................................3
Setup requirements............................................................................................................................................7
Charging the Parent Unit (10 hours) ............................................................................................................6
Positioning the movement Sensor Pad .......................................................................................................8
Setting up the Nusery Unit ............................................................................................................................. 11
Getting to know your monitor...................................................................................................................... 13
Activating and deactivating additional functions ................................................................................20
Troubleshooting ............................................................................................................................................... 22
Limited warranty .............................................................................................................................................. 24
Technical specifications ................................................................................................................................. 24
OWNER’S MANUAL
KEEP YOUR OWNER’S MANUAL FOR FUTURE REFERENCE.
PLEASE READ THE WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING
& USING THE PRODUCT.
FAILURE TO FOLLOW THE WARNINGS AND THE INSTRUCTIONS COULD RESULT IN
SERIOUS INJURY OR DEATH OR DAMAGES TO THE PRODUCT.
THE SENSOR PAD FEATURE IS NOT FOR USE WITH ADULTS, CHILDREN OR INFANTS
OLDER THAN 24 MONTHS.
THE SENSOR PAD IS NOT INTENDED TO BE USED TO DETERMINE IF A CHILD IS OUT OF
THE CRIB.
WARNING
Adult assembly required.
Keep small parts away from children when assembling.
We, at Angelcare®, stand behind all of our products.
If you are not completely satisfied or have any questions,
United States and Canada: Please contact us at: angelcare@cdecinc.ca
Other countries: Please contact your local distributor.
FCC AND IC REGULATIONS
RF radiation exposure statement
The Camera complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. Caution: To maintain the compliance with the FCC’s and Industry Canada’s
RF exposure guideline, install the Camera at least 7.9” (20 cm) from ALL persons. The
transmitter of this device must not be co-located or operating in conjunction with any other
antenna or transmitter.
Industry Canada
This product meets the applicable Industry Canada technical specifications.
CAN ICES-3 (B)/NMB-3 (B)
2
NU
NU
The Parent Unit has been tested and meets the FCC RF exposure
guidelines.
Use of accessories may not ensure compliance with FCC exposure guidelines.
1. THIS PRODUCT CANNOT REPLACE
RESPONSIBLE ADULT SUPERVISION. This product
is designed to aid in the monitoring of your child.
When using th e monitor, you must still provide the
supervision necessary for the continued safety
of your child. Monitoring of premature babies,
or those considered to be at risk, should always
be carried out under the supervision of a health
professional. This monitor SHOULD NOT be used
as a medical device, nor as a device to prevent
Sudden Infant Death Syndrome (SIDS).
2. WARNING Strangulation Hazard — Children
have STRANGLED in cords. Keep adapter cords
out of the reach of
children (more than 3
feet [1 meter] away).
NEVER use Sensor
Pad(s) without the
protective cord covering.
Check protective cord
covering before each use.
Immediately discontinue
use of Sensor Pad(s) if
protective covering is damaged or broken.
3. Never use extension cords with AC adapters.
ONLY use the AC adapters provided.
4. When an AC Adapter is plugged into an
electrical outlet, DO NOT touch the exposed end.
5. ALWAYS be sure that both the transmitter
and receiver are working properly and are within
range of each other. Test monitor before first use,
periodically and when changing location of the
Nursery Unit.
6. A LWAYS be sure to imm ediately check on baby
whenever an alarm sounds.
7. DO NOT use monitor near water (such as bath
tub, sink, etc.).
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DO NOT EXPOSE TO RAIN OR MOISTURE
8. Keep monitor AWAY from heat sources (such
as stoves, radiators, etc.).
9. ALWAYS place both the Nursery Unit and
Parent Unit on a flat surface in an upright position
and allow for proper ventilation. DO NOT place
on sofas, cushions, beds, etc. which may block
ventilation.
10. This monitor uses public airwaves to transmit
signals. The Parent Unit may pick up signals or
interference from other nursery monitors in your
area. Your monitor may even be picked up by
other households. To protect your privacy, make
sure both units are turned OFF when not in use. If
you experience interference, change the channel
on both units.
11. This product is NOT a toy. DO NOT allow
children to play with it.
12. This product contains small parts. Adult
assembly required. Exercise care when unpacking
and assembling the product and keep small parts
away from children.
13. Use and store the monitor at a temperature
between 5 °C and 40 °C.
BATTERY WARNING
14. Use ONLY AA A REC HARGEABLE batteries for
the Pare nt Unit. DO NOT mix old and new batteries.
DO NOT mix alkaline, standard or rechargeable
batte ries. Insert batterie s with correc t polarity. DO
NOT short-circuit supply terminals. ONLY use the
recommended batteries or equivalent (volts and
size) and the correct adapter. Remove batteries
when product is stored for long periods of time or
when batteries are exhausted. Dispose exhausted
batteries properly. DO NOT recharge non-
rechargeable batteries. Rechargeable batteries
are ONLY to be charged under adult supervision.
Keep all batteries away from children.
15. IMPORTANT SAFETY INSTRUCTIONS
15.1 Read these instructions - All the safety
instructions should be read before the product
is operated.
15.2 Keep these instructions. The safety and
operating instructions should be retained for
future reference.
15.3 Heed all warnings – All warnings on the
product and in the operating instructions should
be adhered to.
15.4 Follow all ins tructions – All op erating an d use
instructions should be followed.
15.5 Water and moisture - DO NOT use this
apparatus near water. For example, near a bath
tub, wash bowl, kitchen sink, laundry tub, in a wet
environment or near a swimming pool and the
like. Care should be taken so that objects DO NOT
fall onto units and that liquids are not spilled into
either unit or Sensor Pad through its openings.
15.6 Cleaning - Disconnect all units before
clea ning. DO NOT imme rse in water any pa rt of the
Nursery Unit, Parent Unit. Clean only with dry cloth.
15.7 Ventilation - DO NOT block any ventilation
openings. Allow for proper ventilation when units
are in use. DO NOT cover the Nursery Unit or
Parent Unit with any object such as a blanket.
DO NOT place it in a drawer or in any location
which would muffle the sound or interfere with
the normal flow of air.
15.8 Heat sources - DO NOT install near any heat
sources such as radiators, heat registers, stoves,
TVs or other apparatus (including amplifiers)
that produce heat. Heat can damage the case or
electrical parts.
15.9 Power cord protection - Protect the Sensor
Pad cord and Adapter’s power cord from being
walked on or pinch ed by furniture or other items –
Power supply cords should be routed so that they
are not likely to be walked on or pinched by items
upon or against them, paying particular attention
to cords and plugs, convenience receptacle, and
the point where they exit from the product.
WARNINGS
3
E
N
15.10 Accessories - Only use attachments/
accessories specified by the manufacturer. DO
NOT place this product on an unstable cart,
stand, tripod, bracket or table. The product may
fall, causing serious injury to a child or adult and
serious damage to the product. Use ONLY with a
cart, stand, tripod, bracket or table recommended
by the manufacturer or sold with the product.
Any mounting of the product should follow the
manufacturer’s instructions.
15.11 Unplug this appliance during lightning storms
or when not used for long periods of time.
15.12 Servicing - DO NOT attempt to service
this product yourself as opening or removing
covers (except battery doors) may expose you
to dangerous voltage or other hazards.
15.13 Replacement parts - When replacement
parts are required, be sure the replacement parts
specified by the manufacturer have the same
characteristic as the original part. Unauthorized
substitution may result in fire, electric shock or
other hazards.
15.14 Usage - This baby monitor is intended as
an aid. It is NOT a substitute for responsible and
proper adult supervision and should not be used
as such. Use this appliance ONLY for its intended
use as described in this manual.
15.15 Power Sources - Operate this product only
from the type of power source indicated on the
type plate of the adaptor. If you are unsure of the
type of power supply to your home, consult your
dealer or local power company.
15.16 Overloading - DO NOT overload wall
outlets, extension cords or integral convenience
receptacles as this can result in a risk of fire or
electric shock.
15.17 Object and Liquid Entry - NEVER push
objects of any kind into this product through
casing slots as they may touch dangerous voltage
points or short out parts that could result in a risk
of fire or electric shock. NEVER spill liquid of any
kind on the product.
15.18 Antenna - The antenna used for this
transmitter must be installed to provide a
separation dis tance of at least 7.9 ” (20 cm) from all
persons and mu st not be collocated or ope rating in
conju nction with any other antenna or transm itter.
15.19 Power Lines - An outside antenna system
should NOT be located in the vicinity of overhead
power li nes or oth er electric light or power circuit,
or whe re it can fall into such power lines or circuits
as contact with them may be fatal.
15.20 WARNING Strangulation Hazard —
Children have STRANGLED in cords. Keep
adapter cords out of the
reach of children (more
than 3 feet (1 meter) away).
NEVER use Sensor Pad(s)
without the protective cord
covering. Check protective
cord covering before
each use. Immediately
discontinue use of Sensor
Pad (s) if protec tive covering is dama ged or broken.
15.21 Interference - This monitor uses public
airwaves to transmit signals. The Parent Unit may
pick up signals or interference from other nursery
monitors in your area. Your monitor may even be
picked up by other households. To protect your
privac y, make sure both units are turned OFF when
not in use. If you experience interference, change
the channel on both units.
15.22 Vibration Source - When the monitor is in
use, DO NOT use a bedside crib, crib mobile or
othe r crib accessories that may produce vibr ations .
Other sources of vibrations may include fans,
washing machines, loud music, etc. These sources
of vibration may interfere with the performance
of your Angelcare® monitor and the alarm will
not sound if it continues to detect any movement
other than your baby’s. Be sure all vibration
sources are eliminated before using the monitor.
Yo u ma y ex p eri e n ce f a l se a l a rm s f o r s e ve r a l re a so n s .
The most common reason is the Nursery Unit has
not be en turned OFF af ter you have removed yo ur
b aby f ro m th e c ri b . An o th e r rea s on i s th e S e nso r Pad
has not been placed under the mattress properly.
Be sure the Sensor Pad is on a flat, firm surface
with the printed side facing up. The sensitivity
level may also need to be adjusted. Refer to Step
5. 3. Always be sure to immediately check on baby
whenever an alarm sounds.
15.23 Sensor Pad - If the crib has a spring or slat
base, place a hard board between the crib base
and the Sensor Pad measuring at least 33 x 33 cm
and 6 mm thick . Only use yo ur Angelcare® monitor
in a stati onar y sleep ing environment such as a crib
where the Sensor Pad can rest on a completely
flat, firm surface.
16. IMPORTANT SAFETY INSTRUCTIONS
RELATED TO USE OF BATTERIES
16.1 Use ONLY the type and size of batteries
specified in the owner’s manual. There is a
risk of explosion if batteries are replaced
with an incorrect type.
16.2 Use ONLY AAA rechargeable batteries and/
or the AC Adapters provided for the Parent Unit.
You must use only rechargeable batteries in the
Parent Unit. DO NOT use alkaline batteries or you
will severely damage the unit.
16.3 Charge the batteries for 10 hours prior to first
use . Be sure to have the monito r in the OF F position
during this period. ONLY use the AC Adapters
included with your monitor.
16.4 DO NOT use these adapters with any other
equipments.
16.5 When unplugging the AC Adapter from the
Nursery Unit, be sure it is switched to the OFF
position. If it isn’t, the unit will revert to battery
mode if batteries are installed.
16.6 DO NOT use rechargeable batteries in the
Nursery Unit. Use alkaline batteries ONLY.
16.7 DO NOT dispose batteries in fire. They may
explode. Check with local regulations for possible
special disposal instructions.
16.8 Exercise care in handling batteries in order
not to short out the batteries with conducting
materials such as rings, bracelets and keys.
Overcharging, short circuiting, reverse charging,
mutilation, or incineration of batteries must be
avoided to prevent one or more of the following
occurrences: release of toxic materials, release of
hydrogen and/or oxygen gas and rise in surface
temperature.
4
16.9 DO NOT attempt to recharge batteries
provided with or identified for use with this
product that are not intended to be charged. The
bat teries may leak corrosive ele ctrol yte or expl ode.
16.10 D O NOT attempt to rejuvenate the batteries
provided with or identified for use with this
product by heating them. Sudden release of
battery electrolyte may occur, causing burns or
irritation to eyes or skin.
16.11 If and when necessary, the batteries must be
replaced with identical new ones or equivalent (volts
and size). If a battery to be replaced is connected
with other batteries in series, replace the other
batteries at the same time as well. DO NOT mix
old and new batteries.
16.12 Reverse polarity installation of the batteries
in the end product must be avoided. Reverse
insertion of batteries can cause charging, and
that may result in leakage or explosion.
16.13 Remove batteries from this product if you
store the product over 30 days because the
batteries could leak and damage the product.
16.14 Discard ‘dead’ batteries as soon as possible
since ‘dead’ batteries are more likely to leak in a
product. If a batter y has leaked or vented, it sh ould
be replaced immediately using protective gloves.
16.15 DO NOT store this product, or the
batteries provided with or identified for
use with this product, in high-temperature
areas.
WARNING
(North America Only)
17. Modifications not authorized by the
manufacturer may void use rs autho rity to ope rate
this device.
17.1 NOTE: This equipment has been tested and
foun d to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications.
17.2 H o w e v e r , t h e r e i s n o g u a r a n t e e t h a t i n t e r f e r e n c e
will not occur in a particular installation. If this
e qu ip m en t do e s c a us e ha r mf ul i nt er f er en c e t o ra di o
or television reception, which can be determined
by turning the equipment OFF and ON, the user
is encouraged to try to correct the interference -
by one or more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between
the equipment and receiver.
• Connect the equipment into an
outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
17.3 This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference,
and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
17.4 This device complies with the part 15 of the
FCC Rules and the Industry Canada license -
exempt RSS standards(s). Operation is subject
to the following two conditions:
17.5 (1) This device may not cause harmful
interference, and
17.6 (2) This device must accept any interference
received, including interference that may cause
undesired operation.
5
E
N
IC WARNING:
Lepresent appareil est conforme aux CNR
d'Industrie Canada applicable aux appareils
radio
Exempts de licence. L'exploitation est autorisee
aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout
brouillage radioelectrique subi, meme si le
brouillage est susceptible d'en compromettre le
fonctionnement.
YOU MUST PREPARE:
One hardboard (not included)
Thickness: 1/4’’ (6 mm)
Minimum dimensions:
13’’ x 13’’ (33 x 33 cm)
Maximum dimensions:
equal to the mattress size
WHAT YOU WILL NEED (NOT INCLUDED):
2 Rechargeable AAA Batteries
(for Parent Unit)
2 AAA Alkaline
Batteries
(for Nursery Unit)
IMPORTANT
The hardboard must be larger than
the Sensor Pad surface.
Miniature Philips
Screwdriver
Hardboard
Model AC115
Sound and Movement Monitor
SETUP REQUIREMENTS
INCLUDED:
AC adapter
(for Nursery Unit)
AC adapter
(for Parent Unit)
* Always place Angelcare logo side up *
Wired Movement Sensor Pad 6 Pre-threated cord covers with
Split USB cable
Parent Unit Nursery Unit Tabletop stand
(for Nursery Unit)
2X
2X
6
AC117
& Nursery Unit)
Wireless
CR3032
3V LITHIUM
BATTERY
(for Sensor Pad)
STEP 1 - CHARGING THE PARENT UNIT (10 HOURS)
10
2
3
1
Battery
compartment 1) Remove the batteries
compartment on the
backside. Insert the
provided rechargeable
batteries into the
compartment.
2) Connect the USB plug to
the Parent Unit.
3) Connect the power adapter
with an electrical outlet.
4) Charge the unit for
10 continuous hours prior
to first use.
PARENT UNIT:
TIC Indicator
Micro USB
charging port
Power
On/Off
Menu/
Exit Menu
UP/
Volume +
Down/
Volume -
Rechargeable
batteries
compartment
Confirm Selection/
Pause Sensor Pad
Talk Back
Button
OK
7
E
N
WARNING
STRANGULATION HAZARD.
Children have STRANGLED in cords:
• Keep adapter cords out of the reach of children
(more than 3 feet [1 meter] away).
• Because of the serious strangulation risk to infants
and toddlers, parents and caregivers should never
place the Nursery Unit within 3 feet (1 meter) of a
crib.
• NEVER use Sensor Pad without the cord covers.
Check cord covers before each use to ensure it is
securely placed under the leg of the crib. Discontinue
use of Sensor Pad if any cord covers are damaged or
broken.
• NEVER use extension cords with adapters. ONLY
use the adapters provided. This product is not a toy.
Never allow children to play with it.
STEP 2 - POSITIONING THE MOVEMENT SENSOR PAD
2.1 - SELECT A LOCATION FOR THE NURSERY UNIT
IMPORTANT
Place the crib near a supporting wall and far from air currents. Install the Nursery Unit
on a flat, stable surface facing the crib at a distance of at least 3 feet (1 meter). Make
sure to plug the adapter to the socket outlet nearest to the equipment and that is easily
accessible.
Place the Nursery
Unit at least 3 feet
[1 meter]
from the cot
8
IMPORTANT
If your crib does not have a solid, stable surface for the Sensor
Pad, you will need to place a support under it, to ensure correct
operation of the system.
This hardboard support should be at least 6 mm thick and should
have minimum dimensions of 13’’ x 13’’ (33 x 33 cm). This support
board must be larger than the Sensor Pad surface area.
The Sensor Pad functions with any size and type of mattress except memory-foam
mattresses, hollow frame mattresses and water beds. The hardboard maintains a
constant pressure on the Sensor Pad, enabling it to detect the baby’s movements even
when the baby is at the edges of the crib.
Hardboard
9
E
N
2.3- INSTALL THE SENSOR PAD ON THE MATTERESS SUPPORT
2.2 POWERING THE MOVEMENT SENSOR PAD
1) When using the Sensor Pad for the first time,you will need to insert the
provided CR3032 battery.
2) Remove the battery cover using a coin. Turn in the direction of the
arrow.
3) Place the included battery (CR3032) in the compartment.
Note: The + symbol should be facing up.
4) Replace the battery cover (the two dots will line up).
The Sensor Pad is now ON.
5) Verify the wireless sensor pad is in linking with NU- NU Light Ring
does not flash in light blue.
PAD
INSTALL THE SENSOR PAD ON THE MATTRESS SUPPORT
Angelcare
MATTRESS
PAD
1) Remove the mattress from the crib.
2) Place the Sensor Pad-printed side up-
in the center of the mattress. It should
be centered on the hardboard if your
crib requires a hardboard support.
3) Replace the mattress.
2
10
WARNING
STRANGULATION HAZARD
• Remove all slack from Sensor Pad Cord.
• When lowering the mattress support
as your child grows, slide the vertical
Cord Cover downward so it remains
approximately in the center between
the mattress support and the floor. Slide
the Sensor Pad Cord through the Floor
Cover to eliminate any additional slack.
• The Sensor Pad is not designed
for use with adults, children or infants
older than 24 months.
• Discontinue used of the Sensor Pad
when child is older than 24 months.
Remove Sensor Pad from crib and store
for future use.
• BEFORE FIRST TIME USE: To test
that the unit is ready for use, refer to
instruction manual on how to test that
the installation has been done correctly.
STEP 3 - SETTING UP THE NURSERY UNIT
Select a location for the Nursery Unit that is at least 1 m away from the crib.
1
1) Remove the batteries cover and
insert 2 AAA Alkaline Batteries
(not included)
Note:
The batteries maintain power
supply in case of power outage.
MUST BE MORE THAN
3 FEET (1 METER) AWAY
Sensor Pad 5
6
4 3 2 1
2
2) Install the Nursery Unit on a flat,
stable surface facing the crib at
a distance of at least 3 feet
(1 meter) and plug the Sensor
Pad cord into the Nursery Unit.
3) Check to make sure the Sensor
Pad has not moved from
position.
4) Place the mattress back inside
the crib.
5
6
5) Connect the USB plug to the
Nursery Unit.
6) Connect the USB plug with the
power adapter and then with an
electrical outlet.
11
E
N
Note: Each time you power ON your Nursery Unit, the internal thermometer will need to
calibrate to ensure accuracy. This automatic process will take approximately 30 minutes.
The colour changing temperature display, by default, will be turned “OFF”. You may turn
this feature “ON” in the settings mode on your Parent Unit.
NURSERY UNIT:
Power ON/OFF Light Indicator
Low Batteries Light Indicator Temperature
Indicator
ON/OFF /
Pager
Pause Movement
Sensor Pad
Movement
Sensor Pad
Sensitivity
switch
Power
ON/OFF
Speaker Micro USB
Port
Microphone
Sensor Pad Indicator/
Temperature Indicator
Batteries
Compartment
STEP 4 - TURNING ON YOUR MONITOR
YOU ARE NOW READY TO USE YOUR MONITOR
The Angelcare® monitor can be used with the pre-program factory settings or you can also
customize your settings to your preference.
DEFAULT SETTINGS
Detection Mode:
Movement: ON
Sound: ON
Sound transmission (VOX): OFF
Temperature Unit: Fahrenheit - USA
Celsius - Canada
Temperature Alarm: OFF
Temperature Alarm Setting: High: 86˚F / 30˚C
Low: 66˚F / 19˚C
12
TURN ON YOUR MONITOR
Press ON/OFF
on the Parent
Unit
Press ON/OFF
on the Nursery
Unit
1) Press the Parent Unit ON/OFF
button for 2 seconds.
2) Press the Nursery Unit Power
ON/OFF button for 2 seconds.
NOTE:
The screen of the Parent Unit will
flashes the out-of-range icon till it
displays the room temperature and
function icons. The connecting process
should be done within 30 seconds. If
this sequence is not completed within
30 seconds you will need to switch the
units off and start again.
When Parent Unit is turned ON and Nursery Unit is OFF or if there
is a lost connection between the 2 units (refer to troubleshooting).
The Out-of-range icon will blink on the screen and the Parent Unit
will beep.
IMPORTANT ICONS
Detection mode icons: Indicates monitor detection mode
Movement only Sound only Movement, Sound & “TIC”
Movement & Sound Movement & “TIC”
VOX icon: Indicates when the Nursery Unit is in VOX mode
Sound activated transmission (VOX ON)
Continuous sound transmission (VOX OFF)
Volume and VOX Sensitvity Level
Connection icon: Indicates the connection quality between the
Parent Unit and the Nursery Unit
Out-of-range Poor connection
Medium connection Good connection
Temperature display: Indicates room temperature
Temperature alerts icons: Indicates Temperature
Alarm is active
Too Warm Too Cold
Battery level icon: Indicates Parent Unit battery life
Full 1/2 Empty Charging
13
E
N
STEP 5 - TESTING AND GETTING TO KNOW YOUR MONITOR
The Angelcare® monitor can be used with the pre-program factory settings or you can also
customize your settings to your preference.
All changes and
adjustments made in
the main menu will not
be activated unless you
confirm them by pressing
the EXIT button.
IMPORTANT
When in MENU mode, sound
transmission between Parent and
Nursery Units will be temporarily
deactivated.
5.1 - MENU ACCESS AND CHANGING THE SETTINGS
The MENU settings are accessed by pressing and HOLD the MENU button on the Parent
Unit. The MENU functions are in a loop. Each time you press the OK button briefly you
move on to the next MENU function. The MENU functions are in the following order
PRESS AND HOLD: Movement & ‘’TIC” .….….….….….….….….….….….….….….….….….….….…. STEP 5.2
PRESS 1 TIME: Sound ….….….….….….….….….….….….….….….….….….….….….….….….….….….….…. STEP 5.5
PRESS 2 TIMES: Sound Transmission (VOX) .….….….….….….….….….….….….….….….….…. STEP 5.6
PRESS 4 TIMES: Temperature .….….….….….….….….….….….….….….….….….….….….….….….…. STEP 5.7
NOTE:
By continuing to press the OK button you will be continuously moving through the loop.
Once you have selected your preferred settings you must press EXIT MENU or your
changes will not be saved.
5.2 - SETTING THE SENSOR PAD
SET THE MOVEMENT DETECTION
Allows you to detect the baby’s movements.
1
2
3
1) Press and HOLD the MENU button till
the Movement monitoring icon blinks.
The movement monitoring
icon will blinks.
2) Use the UP and DOWN arrows to
activate or deactivate movement
detection.
3) Press the OK button to confirm
your choice.
14
SET THE TIC FUNCTION
Allows you to detect baby’s movements as well as hear a TIC sound at each movement.
(This function can ONLY be activated in conjunction with the Movement Function).
IMPORTANT
To activate the ‘’TIC’’ Function, the movement detection needs to be ON.
5
4
6
7
4) If you have activated the movement,
the Parent Unit will allow you to set
the ‘’TIC’’ function.
The movement
monitoring and
“TIC’’ icons will blink
5) Use the UP and DOWN arrows to
set the TIC function.
6) Press the OK button to confirm
your choice.
7) Press the EXIT button to test the
Sensor Pad.
TO TEST THE SENSOR PAD
MOVEMENT MODE NEED TO BE ACTIVATED:
1 2
1) Move your hand lightly on the mattress.
NOTE:
The Parent Unit will emit a
‘’TIC’’ sound (when activated) and
will flashes every 5 seconds.
2) Remove your hand from the mattress.
After 15 seconds you will hear a
‘TIC’ pre-alarm sound, and 5 seconds
later the Movement Alarm will trigger.
3) Repeat by moving your hand lightly
in all four corners of the mattress.
Ensure the Nursery Unit Movement
Indicator is still flashing.
MOVEMENT ALARM
• If NO movement is detected after 15 seconds you will hear
a single ‘TIC’ pre-alarm sound from the Nursery Unit.
• If after a further 5 seconds there is still NO movement
detected both the Parent Unit and Nursery Unit speakers
will emit loud warning sound.v
• Nursery Unit will flash red light.
• Sensor Pad Icon and sound level bar on Parent Unit will flash.
15
E
N
IF THE ALARM DOES NOT SOUND
• Avoid contact with crib while Sensor Pad is in operation.
• Place crib near a supporting wall.
• Adjust Sensor Pad sensitivity level.
• Turn OFF crib mobile, fans, loud music or anything else that may cause vibration.
TO STOP THE ALARM
Place your hand
back on the
mattress.
Press PAUSE button
on the Nursery Unit
Press PAUSE
SENSOR PAD
button on the
Parent Unit
OR OR
5.3 - PAUSING AND RESTARTING THE SENSOR PAD
Allows you to pause the Sensor Pad if you remove baby from the crib, e.g. for feeding or comforting.
Pause Sensor Pad
1) From the Parent Unit, press and
hold Pause Sensor Pad button
for at least 2 seconds.
OR
From the Nursery Unit, press
the Pause button
IMPORTANT
• If you do not pause the Sensor Pad, the alarm will sound if there is no movement after
20 seconds.
• Ensure to unpause the Sensor Pad before putting baby in the crib.
5.4 ADJUST THE SENSOR PAD SENSITIVITY LEVEL:
To ensure adequate monitoring of your baby’s movements, you can adjust the sensitivity of the
Sensor Pad. Set a high sensitivity for a newborn and a lower sensitivity as baby grows and gains
weight. A thicker mattress will also need a higher sensitivity. Slide the Nursery Unit sensitivity
level button to select between low, medium or high level.
For optimal results begin with medium
sensitivity level, adjusting the sensitivity
by increasing or decreasing as required.
NOTE:
If you are experiencing false alarms,
adjust the sensitivity level.
16
IMPORTANT
• The Sensor Pad is not designed for use with adults, children or infants older than
24 months.
• Once you are finished using the Sensor Pad, please remove it from the baby’s crib
and store it away.
5.5 - SOUND
TO ACTIVATE SOUND:
1
2
3
1) Press and hold the MENU Button
then press the OK button till the
Sound Monitoring icon blinks.
The sound monitoring
icon will blinks.
2) Using the UP and DOWN arrows, turn
the function ON or OFF.
3) Press the EXIT button to confirm
your choice.
TO TEST SOUND:
Ask someone to speak into the Nursery
Unit or place the unit near a radio to ensure
that sound is being picked up.
IMPORTANT
To avoid feedback (whistling), keep both
units at least 10 feet apart (3 meters).
apart.
IF YOU HEAR NO SOUND:
• Check that both units are powered ON.
• Check that both units are plugged into
functioning electrical outlets.
• Check the batteries in both units
(replace or recharge them if necessary).
• Bring the Parent Unit closer to the
Nursery Unit.
ADJUST THE
SOUND LEVEL
PUT IN
MUTE MODE
PUT IN DIALOGUE
MODE
Raise
volume
Lower
volume Press the
VOLUME - till
L0 is being
displayed
Press and
hold talk
button to
speak to
baby
17
E
N
5.6 - SOUND TRANSMISSION (VOX)
Your monitor is ‘Sound Activated’. This means that it will transmit sounds only when it
detects them. It will detect even the softest levels of crying.
To save power, after 10 seconds, the sound transmission will stop if no sound is detected.
Once sound is detected transmission will automatically activate.
1
2
3
1) Press and hold the MENU button then
press the OK button till the VOX icon blinks.
The VOX icon will blinks.
2) Use the UP and DOWN arrows to
activate or deactivate VOX.
3) Press the OK button to go to the next
setting or press the EXIT button to
confirm your choice.
TO ADJUST SOUND SENSITIVITY (VOX)
The sensitivity of the microphone is adjustable and has 4 levels (the most sensitive is
level 4). This means that sound will only transmit based on the level that you set.
2
3
1
TO
1) When the Sound Transmission is ON
(VOX ON) press and hold the MENU
button then press OK button till VOX
icon blinks.
The VOX icon will blinks.
2) Use the UP and DOWN arrows to select
desired microphone sensitivity level.
3) Press the OK button to go to the next
setting or press the EXIT button to
confirm your choice.
5.7 - TEMPERATURE
TO SELECT TEMPERATURE IN CELSIUS OR FAHRENHEIT
1
2
3
1) Press and hold the MENU button
then press OK button till the ˚F /˚C
icon blinks.
The ˚F /˚C icon will blinks.
2) Use the UP and DOWN arrows to
select temperature in Celsius or
Fahrenheit.
3) Press the OK button to go to the next
setting or press the EXIT button to
confirm your choice.
18
TO ACTIVATE THE TEMPERATURE ALARM
1
2
3
1) Press and hold the MENU button
then press OK button till the
Temperature Indicator icon blinks.
The Temperature Indicator
(Low and High) will blinks.
2) Use the UP and DOWN arrows to
turn temperature alarm ON or OFF.
3) Press OK button to confirm your
choice.
TO SET TEMPERATURE RANGE
1
2
3
1) Press the OK button once more.
The Snow Flake (Low
Temperature icon) will blinks.
2) Use the UP and DOWN arrows to set
the LOW temperature alarm (41 to
66,5° Fahrenheit / 5 to 19° Celsius).
3) Press the OK button to confirm your
choice.
The low temperature range is 41 to 66,5°F
(5 to 19°C) and high temperature range is
71 to 98,6°F (22 to 37°C).
4
5
6
4) Press the OK button once again.
The Sun (High Temperature
icon) will blinks.
5) Use the UP and DOWN arrows to set
the HIGH temperature alarm (71 to
98,6° Fahrenheit / 22 to 37° Celsius).
6) Press the OK button to go to the next
setting or press the EXIT button to
confirm your choice.
NOTE:
Make sure to turn ON Temperature alarm to be able to set Temperature range.
TEMPERATURE ALARM
• Alarm activates when the temperature reaches the maximum or minimum set
temperature.
• Parent Unit will emit 3 consecutive beeps, every 5 seconds if the temperature reaches
levels out of your chosen range. The relevant icon will flash on the Parent Unit screen
to alert you.
• The Nursery Temperature Indicator will turn blue if the temparature is too cold or red
if the temperature is it too hot.
19
E
N
STEP 6 - ACTIVATING AND DEACTIVATING ADDITIONAL FUNCTIONS
6.1 - ACTIVATE OR DEACTIVATE TEMPERATURE INDICATOR ON NURSERY UNIT
With this option the Nursery Unit Temperature Indicator will light up in colour when the
temperature goes above or below your preferences. If the temperature goes above your
set preferences and this option is turned ON, the light on the Nursery Unit’s will turn to red
instead of the default white. If the temperature goes under the set preferences, then the
light will turn blue.
Red - Room temperature is too hot
Blue - Room temperature is too cold
White - Room temperature is good
ON/OFF
Temperature
light
6.2 - OUT OF RANGE SETTINGS
Your monitor has an Out-of-Range alarm that advises you when your two units are not
communicating. Out-of-Range situations can be caused by distance or by physical interferences.
RANGE:
Open field (Open area without obstructions): up to 755 feet (230 meters).
OUT-OF-RANGE ALARM
• Alarm activates when your two units are not communicating.
• The Parent Unit will emit a double beep every 16 seconds.
• Out-of-Range Icon will flash on the screen.
IMPORTANT
If you turn the Nursery Unit OFF the Out-of-Range Alarm will sound. Turn the Nursery
Unit ON again to reactivate the link.
TO STOP THE OUT-OF-RANGE ALARM:
Press 2 seconds
to turn the Parent
Unit OFF
Turn the Nursery
Unit ON
OR
20
6.3 - PAGER
Allows you to locate the Parent Unit.
Press and hold
the Pager button
TO LOCATE THE PARENT UNIT
Press and hold the Nursery Unit Pager
button on the side of the Nursery Unit.
The Parent Unit will emit a paging
sound.
TO STOP THE PAGING SOUND
Press any button on the Parent Unit or
the Pager button on the Nursery Unit.
21
E
N
TROUBLESHOOTING
TAKING CARE OF YOUR RECHARGEABLE BATTERIES
• Ensure that you fully charge your batteries for 10 hours before their first use.
• To maintain maximum battery life it is recommended that you fully discharge your
batteries periodically. Battery performance can be diminished by leaving the batteries
constantly charging. If your parent unit is not in use, please turn it off.
• Inadequate battery power can impair the performance of your monitor. If you are not
happy with the performance of your Parent Unit Monitor please replace the rechargeable
batteries (2 x NiMH Rechargeable Batteries).
• It is advisable to change the batteries every 6 months.
Power On/Off Light Indicator
Low Battery Light Indicator
Flashing green Nursery unit is using the
back-up batteries
Flashing yellow Nursery Unit batteries are low
Steady green Monitor is activated
Sensor Pad Light Indicator
Temperature Indicator
Flashing red No movement is detected or
Sensor Pad is disconnected
Flashing white Monitor is paused
Steady Red Room temperature is too hot
Steady Blue Room temperature is too cold
Steady White Room temperature is good
FALSE ALARMS
• Turn OFF the Nursery Unit.
• Make sure there is no bedding between the mattress and the Sensor Pad.
• If the crib has a spring or slat base, place a hardboard between the crib base and the
Sensor Pad measuring at least 13’’ x 13’’ (33 x 33 cm) thick.
• Make sure Sensor Pad is positioned as described under the setup requirements.
Sensitivity may need to be adjusted, refer to Step 5.4.
ALARM WILL NOT SOUND
• Avoid contact with the crib when the monitor is ON.
• Place crib near a solid supporting wall to avoid Sensor Pad from detecting movement
from outside the crib.
• Turn OFF crib mobile, fans, loud music or anything else that may cause vibration.
• You may need to decrease the sensitivity, refer to Step 5.4.
NURSERY UNIT POWER ON INDICATOR (GREEN LIGHT) DOES NOT LIGHT UP
• Check connections or change to another electrical outlet.
• Press the Nursery Unit ON/OFF button for 2 seconds to turn the Nursery Unit ON.
22
WEAK RECEPTION
• Bring units closer together.
• Change the position of one or both units.
• Place units on a flat surface away from baby’s reach.
• Replace the batteries or recharge the Parent Unit.
STATIC, DISTORTION, INTERFERENCES (FROM OTHER
MONITORS, WIRELESS PHONES, WALKIE-TALKIES, ETC...)
• Rotate the Parent Unit or move it away from source of interference.
FEEDBACK (LOUD NOISES EMITTED FROM THE PARENT UNIT)
• Move units farther apart (at least 3 meters apart).
• Decrease volume on the Parent Unit.
THE PARENT UNIT SCREEN IS BLACK (PARENT UNIT IS OFF)
• Turn the Parent Unit back ON by pushing and holding the power button.
• Replace the batteries or recharge the Parent Unit.
SENSOR PAD LIGHT INDICATOR FLASHING RED
(MONITOR IS BARELY DETECTING MOVEMENT)
• Make sure there is no bedding between the mattress and the Sensor Pad.
• The Sensor Pad must rest on a completely flat and firm surface. If the crib has a spring
or slat base, place a hard board between the crib base and the Sensor Pad measuring
at least 13’’ x 13’’ (33 x 33 cm) thick.
• Make sure Sensor Pad is positioned as described under the setup requirements.
Sensitivity may need to be adjusted, refer to Step 5.4.
NO POWER
• Check or replace batteries.
• Make sure Monitor is ON.
NURSERY UNIT POWER ON INDICATOR (GREEN LIGHT) DOES NOT LIGHT UP
• Check connections or change to another electrical outlet.
• Press the Nursery Unit ON/OFF button for 2 seconds to turn the Nursery Unit ON.
23
E
N
TECHNICAL SPECIFICATIONS
Range:
Open field (Open area without obstructions):
up to 755 feet (230 meters).
Power Supply:
2 AAA alkaline batteries (not included) or
100/240V AC/5V DC adapter for Nursery Unit.
2 AAA rechargeable batteries and 100/240V
AC/5V DC adapter for the Parent Unit.
Caution: To reduce the risk of electric shock, do
not expose this product to rain or moisture.
Danger of explosion if batteries are incorrectly
replaced. The battery included for the Parent
Unit is 2 AAA NIMH rechargeable batteries,
manufactured by GPI INTERNATIONAL LIMITED
(GN60AAAHC, 1.2V 600mAh). Only use the
Angelcare recommended replacement battery.
To obtain information on replacement batteries
please contact Angelcare customer service:
www.angelcarebaby.com or contact your local
distributor. Instructions will be included with
the replacement battery. Dispose of exhausted
batteries properly according to your local
ordinances. Keep all batteries away from children.
Batteries:
• DO NOT mix old and new batteries.
• DO NOT mix alkaline standard (carbon-zinc),
or rechargeable (NI-CD, NIMH, etc.) batteries.
CAUTION: RISK OF EXPLOSION IF BATTERY
IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS.
Transmission:
Transmission between the Parent Unit and the
Nursery Unit is made on 1.92 to 1.93 GHz frequency
for North America.
LIMITED WARRANTY
Angelcare® warrants to the original owner of this
product that Angelcare® monitor is free from any
material and workmanship defects for the term of
the warranty period (see warranty table below to
determine the warranty for your country). If this
monitoring system fails to function properly when
used as directed under normal conditions and during
the warranty period, Angelcare® will either repair or
replace the product, at our discretion, free of charge.
Please contact your local distributor to validate
warranty and warranty period.
The product must be accompanied by a proof
of purchase, either a bill of sale or other proof
that the monitoring system is within the warranty
period. Angelcare® will bear the cost of repairing or
replacing the product and shipping it back to you.
This warranty does not apply to a product which
has been damaged as a result of improper
maintenance, an accident, improper voltage
supply or any other form of misuse. The warranty
is also void if the owner repairs or modifies the
product in any way. Angelcare® is not liable for
any incidental or consequential damages with
regard to this product. The warranty also excludes
any liability other than what is stated above. No
other warranty is given.
This warranty does not cover products and
accessories which are not Angelcare-branded, or
any problems that result from usage that is not
in accordance with product instructions, failure
to follow the product instructions, or problems
caused by using accessories, parts or components
not supplied by Angelcare.
LEGAL RIGHTS VARY FROM COUNTRY TO
COUNTRY. SOME COUNTRIES DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATIONS MAY NOT APPLY TO YOU.
WE ARE NOT IN ANY WAY RESPONSIBLE FOR
ANY OUTCOME RESULTING FROM THE USE OF
THIS PRODUCT.
IMPORTANT! This Angelcare® monitor is a personal
care product. Please do not return this product
to the store. If you have questions or need help,
please call your distributor before returning this
product.
PROTECT THE ENVIRONMENT
This electronic equipment contains reusable
material and must not be disposed with
domestic waste. Please take it to a collecting
point for electric and electronic equipment
(ask your local authorities for details).
WARRANTY TERM PER COUNTRY
North America 1 year
24
25
E
N
SAR Information Statement
Your baby monitor Parent Unit is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radiofrequency (RF)
energy set by the Federal Communications Commission of the the U.S. Government.
These limits are part of comprehensive guidelines are based on standards that were
developed by independent scientific studies. The standards include a substantial safety
margin designed to assure all persons, regardless of age and health. The exposure
standard for the Parent Unit employs a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. Test for SAR are
conducted with the Parent Unit transmitting at its highest certified power level in all
tested frequency bands.
Although the SAR is determined at the highest certified power level, the actual SAR level
of the Parent Unit is designed to operate at multiple power levels so as to use only the
power required to reach the Nursery Unit. In general, the closer you are to Nursery Unit,
the lower the power output. Before a baby monitor model is available for sale to the
public, it must be tested and certified to the FCC that it does not exceed the limit established
by the government adopted requirement for safe exposure. The tests are performed in
positions and locations (e.g. in front of face and the worn on the body) as required by FCC
for each model. The highest SAR value for the Parent Unit when tested for use in front of
face is 0.043W/Kg and when worn on the body is 0.125W/Kg (Body-worn measurements
differ among various models, depending upon available accessories and FCC requirements).
While there may be difference between the SAR levels of various Parent Units and various
positions, they all meet the government requirement for safe exposures. The FCC has
granted an Equipment Authorization for this model Parent Unit with all reported SAR levels
evaluated in compliance with the FCC RFexposure guidelines. SAR information on this
model Parent Unit is on file with the FCC and can be found under the Display Grant
section of http://www.fcc.gov/oet/fccid after searching on FCC ID:N7TAC117R.
In the United States and Canada, the SAR limit for the Parent Unit is 1.6 watts/kg (W/kg)
averaged over one gram of tissue. The standard incorporates a substantial margin of
safety to give additional protection for the public and to account for any variations in
measurements.
IC STATEMENT
This device complies with Industry Canada license-exempt RSS standard(s)
Operation is subject to the following two conditions:
(1)This device may not cause interference, and
(2)This device must accept any interference, including interference that may cause
undesired operation of the device.
This equipment complies with IC radiation exposure limits set forth for satisfying RF
exposure compliance. This transmitter must not be co-located or operation in conjunction
with any other antenna or transmitter.
These requirements set a SAR limit of 1.6W/kg averaged over one gram of tissue.
The highest SAR value for this Parent Unit when tested for use in front of face is
0.043W/Kg and when worn on the body is 0.125W/Kg. This device was tested for typical
body-worn operations. To comply with RF exposure requirements, 0 mm testing
separation distance was done between testing BODY and the Parent Unit, including
antenna. Third-party belt-clips, holsters, and similar accessories used by this device
should not contain any metallic components. Body-worn accessories that do not meet
these requirements may not comply RF exposure requirements and should be avoided.
Use only the supplied antenna.
26
27
E
N
IM403-INT-14072017
www.angelcarebaby.com

Navigation menu
