Shenzhen skyworth RGB electronic co., LTD. Model: NTUD - U5 Operation Instruction Respect of customer, sincerely thank you for purchasing SKYWORTH equipped with wireless WIFI NTUD - U5 - type USB peripheral products. This product can support USB2.0 protocol, based on the IEEE802.11 a/b/g/n/ac BT5.0 standard design. With all the way to send and receive all the way (2T2R) dual channel work, maximum transmission rate of up to 866 Mbps.Ensure that users browse and download data flow, security and stability. NTUD - U5 wireless WIFI USB peripheral product support Windows XP/Vista / 7 / Linux operating system.In SKYWORTH TV, have complete embedded in the product and the driver, without user to install, and at the same time support Linux and Android. Used in TV production operation is as follows: 1. Turn on the TV, switch to the "home page" interface. 2. Select "Settings" feature. "OK" to enter 3. Select "network setup" function. "OK" to enter; 4. Choose the "wireless network", "OK" to enter;
5. According to the needs, select "auto search", "manual connection", etc. Press the "OK" to enter 6. Choose their own after the AP name "OK" to enter, Enter the password. Television system has the memory function, for the first time to use should be according to the above steps, later need not operation, boot automatically connected.If need to change the AP or change the mode of connection, need according to the above steps again. Extreme Test Temperature:0 °C to +60 °C Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is - connected. - Consult the dealer or an experienced radio/television technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation. Regulation information This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. (2) This compliance to FCC radiation exposure limits for an uncontrolled environment, and minimum of 20cm separation between antenna and body. (3) The device is going to be operated in 5150~5250MHz frequency range. It is restricted indoor environment only. (4) Manual Information to the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. (5) The end product must carry a label stating “Contains Transmitter Module FCC ID: 2ANM3NTUDU5” or shall use e-labeling.
