Darfon Electronics VGP-WKB15 Keyboard User Manual KB MANUAL
Darfon Electronics Corp Keyboard KB MANUAL
User Manual
Search
VAIO User Guide J Series SVJ2021 Series Back | Back to Top
How to Use Describes the features of the keyboard, such as keys, buttons and indicator lights.
key [Details]
key
Function keys [Details]
key
/ key
key
key
/ key [Details]
key
Power switch of the keyboard
key
key
key
button
button
Sleep button [Details]
Volume control buttons [Details]
Muting button [Details]
key
key
key [Details]
(Windows) key
key
Space bar
key
Applications key
Directional arrow keys
Numeric keypad
Connect indicator [Details]
Battery indicator [Details]
Caps lock indicator [Details]
There is a raised dot on the , and keys.•
After 10 minutes of idle time, the keyboard enters the power saving mode and all indicator lights turn off.•
1
Search
VAIO User Guide J Series SVJ2021 Series Back | Back to Top
How to Use The remaining battery power of the keyboard can be checked by the battery indicator.
Check the battery indicator of the keyboard.
It blinks when the battery is running out of power.
The indicator is only a guide and may not show the remaining battery power accurately, depending on the AA
battery.
If you intend not to use the keyboard for a long time, slide the power switch to to extend battery life.•
Parts and Controls of the Keyboard
Replacing the AA Battery of the Keyboard
© 2012 Sony Corporation
1
Search
VAIO User Guide J Series SVJ2021 Series Back | Back to Top
How to Use Change the AA battery in the keyboard when the battery power becomes low.
Set the power switch of the keyboard to .
Turn over the keyboard, and then push the center of the cover in the direction shown in the illustration
below.
Remove the old battery and insert a new AA alkaline battery (minus (-) end first), then close the cover.
Set the power switch of the keyboard to .
Use a new AA alkaline replacement battery.•
If you do not intend to use the keyboard for a while, set the power switch of the keyboard to . If you
do not intend to use the keyboard for an extended period of time, remove its AA battery.
•
When the battery power becomes low, replace with a new AA battery promptly. Keeping a depleted
battery in the keyboard may cause battery leakage.
•
Since the keyboard cannot be used with a commercially available rechargeable battery, use a non-
rechargeable AA battery. If you use a rechargeable battery, battery leakage may occur, resulting in a
malfunction.
•
Do not recharge a dry cell AA battery.•
Refer to the supplied safety information manual.•
Parts and Controls of the Keyboard
Checking the Remaining Battery Power of the Keyboard
© 2012 Sony Corporation
1
Mouse and dongle are arranged in pairs.
Keyboard and dongle are arranged in pairs
MOUSE FCC ID:O62VGP-WMS22
K/B FCC ID:O62VGP-WKB15
DONGLE FCC ID:O62VGP-WRC7
