FENDA TECHNOLOGY AMBOX Huawei Bluetooth Speaker User Manual B010005 SWAN User Guide 01 EN 20130318

SHENZHEN FENDA TECHNOLOGY CO., LTD. Huawei Bluetooth Speaker B010005 SWAN User Guide 01 EN 20130318

Manual r1

Connecting your SWAN to Bluetooth devicesI. Connecting to one Bluetooth deviceAfter you turn the SWAN on, it automatically searches for nearby Bluetooth devices and enters standby mode. On the device you want to pair with the SWAN, turn on Bluetooth. After the SWAN is found on the device, touch HUAWEI SWAN to pair it with the SWAN.Note: On some Bluetooth devices, you may need to enter a password to set up a connection. The default password is 0000.The next time you turn on the SWAN, it automatically searches for and pairs with the Bluetooth device that it paired with previously. If no such devices are found, your SWAN will remain in standby mode. II. Connecting to two Bluetooth devicesThe first time you pair the SWAN with two Bluetooth devices, do the following:1. Pair the SWAN with a Bluetooth device.2. Touch and hold to disconnect from the device and enable the SWAN to enter the ready-to-pair mode.3. On the second Bluetooth device, search for and pair with the SWAN.4. On the first Bluetooth device, search for and pair with the SWAN.Note: The SWAN can work with only one Bluetooth device at a time. If you have two Bluetooth devices paired, pause all operations on one device to have the SWAN run the operations on the other device.If you do not clear the pairing information from two previously used devices, your SWAN will connect to them automatically when both are available.Note:Some Bluetooth devices do not support the Advanced Audio Distribution Profile (A2DP) and cannot use the SWAN to play media files. For media playback software incompatible with the SWAN will not allow the , ,and keys to work. Before using the SWAN, make sure you have compatible Bluetooth devices and media playback software.Please visit www.huaweidevice.com/worldwide/support/hotline for recently updated hotline and email address in your country or region.Model: W18W B010005_01II. Indicators and port1234765Bottom view Top viewHUAWEI Bluetooth Speaker45231Getting to know your SWANThe HUAWEI Bluetooth Speaker (SWAN for short) is a Bluetooth-capable device that lets you play music wirelessly from other Bluetooth devices. It automatically searches for nearby Bluetooth devices after you power it on. The SWAN can be paired with two Bluetooth devices simultaneously, but can work with one device at a time. When paired with your phone, the SWAN functions as a speaker and microphone when you are on a call in handsfree mode.Before you start using your SWAN, let's take a look at its features and learn how to use them.I. Power button and keysUser GuideSWAN1. Power button* Switch the power button to turn the SWAN on or off.* When the battery level is critically low, the SWAN automatically turns off. If this happens, charge the battery for a while and switch the power button to the off position then the on position to turn on the SWAN.2. Volume up key 5. Volume down key* To increase the SWAN volume, touch or touch and hold . To decrease the SWAN volume, touch or touch and hold .3. Previous 6. Next* To play the previous or next song in a playlist on a paired Bluetooth device, touch or .* When the SWAN is pairing with a Bluetooth device, touch or to switch between voice instructions and alert tones.4. Bluetooth pair key* When music is playing, touch to pause or resume the playback.* When a call comes in, touch to answer the call or touch and hold to dismiss the call. To end the call, touch again.When you are in a call in handsfree mode, touch and hold to switch from the SWAN handsfree mode to the phone mode. To switch back, set the answer mode on your phone to Bluetooth.* When you are not in handsfree mode, touch and hold to disconnect the SWAN from its paired Bluetooth device. The SWAN is then ready to pair with another device.7. Microphone1. Key indicatorThis indicator turns on after the SWAN turns on or when you perform an operation. It will turn off when the SWAN is inactive for a short while.2. Bluetooth pairing indicatorWhen the SWAN is pairing with another device, this indicator blinks quickly. If the pairing fails, this indicator blinks slowly. If the SWAN successfully pairs with the device, this indicator turns off.3. Breath indicatorWhen the SWAN is on, this indicator blinks slowly. When a call comes in, this indicator blinks quickly.4. Charging indicatorWhen the SWAN is charging, this indicator turns on. After the battery is fully charged, this indicator turns off.5. Charging portThis port connects the SWAN to a power adapter (5 V output) through a USB cable. You may also connect the SWAN to a computer’s USB port to charge the battery.Safety information This section contains important information about the operation of your device. It also contains information about how to use the device safely. Read this information carefully before using your device.Operating environment* The device supports a transmission distance of up to 10 meters. It is recommended that you place your Bluetooth device within a 10-meter range from the speaker.* Avoid dusty, damp, or dirty environments. Avoid magnetic fields. Using the device in these environments may result in circuit malfunctions. * Ideal operating temperatures are 10℃ to 35℃. Ideal storage temperatures are -10℃ to 40℃. Extreme heat or cold may damage your device or accessories. * Do not expose your device to direct sunlight (such as on a car dashboard) for prolonged periods. * To protect your device or accessories from fire or electrical shock hazards, avoid rain and moisture. * Keep the device away from sources of heat and fire, such as a heater, microwave oven, stove, water heater, radiator, or candle. * Do not place sharp metal objects, such as pins, near the earpiece or speaker. The earpiece may attract these objects and result in injury. * Do not allow children or pets to bite or suck the device or accessories. Doing so may result in damage or explosion. * Observe local laws and regulations, and respect the privacy and legal rights of others. Child's safet* Comply with all precautions with regard to child's safety. Letting children play with the device or its accessories may be dangerous. The device includes detachable parts that may present a choking hazard. Keep away from children. * The device and its accessories are not intended for use by children. Children should only use the device with adult supervision. Battery safety* The device has a built-in, non-removable battery. Do not attempt to remove the battery, otherwise the device may be damaged. To replace the battery, take the device to an authorized service center.* If the device has not been used for a long time, charge the battery before you turn on the device.Cleaning and maintenance* Keep the device and accessories dry. Do not attempt to dry it with an external heat source, such as a microwave oven or hair dryer. * Do not expose your device or accessories to extreme heat or cold. These environments may interfere with proper function and may lead to fire or explosion. * Avoid collision, which may lead to device malfunctions, overheating, fire, or explosion. * Before you clean or maintain the device, stop using it, stop all applications, and disconnect all cables connected to it. * Do not use any chemical detergent, powder, or other chemical agents (such as alcohol and benzene) to clean the device or accessories. These substances may cause damage to parts or present a fire hazard. Use a clean, soft, and dry cloth to clean the device and accessories.* Do not dismantle or remanufacture the device and its accessories. This voids the warranty and releases the manufacturer from liability for damage. In case of damage, contact an authorized service center for assistance or repair.Disposal and recycling informationtry to correct the interference by one or more of the following measures:--Reorient or relocate the receiving antenna.--Increase the separation between the equipment and receiver.--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.--Consult the dealer or an experienced radio/TV technician for help.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.Caution: Any changes or modifications to this device not expressly approved by Huawei Technologies Co., Ltd. for compliance could void the user's authority to operate the equipment.Legal NoticeCopyright © Huawei Technologies Co., Ltd. 2013. All rights reserved. Trademarks and Permissions , , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd.The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Huawei Technologies Co., Ltd. is under license. Other trademarks, product, service and company names mentioned may be the property of their respective owners. Hereby, Huawei Technologies Co., Ltd. declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.For the declaration of conformity, visit the web site www.huaweidevice.com/certification.The following marking is included in the product:This device may be operated in all member states of the EU.--Observe national and local regulations where the device is used.--This device may be restricted for use, depending on the local network. FCC Regulatory ComplianceFCC RF warning statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.FCC statementThis equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to This symbol (with or without a solid bar) on the device, batteries (if included), and/or the packaging, indicates that the device and its electrical accessories (for example, a headset, adapter, or cable) and batteries should not be disposed of as household garbage. These items should not be disposed of as unsorted municipal waste and should be taken to a certified collection point for recycling or proper disposal.For more detailed information about device or battery recycling, contact your local city office, household waste disposal service, or retail store.Disposal of the device and batteries (if included) is subject to WEEE Directive Recast (Directive 2012/19/EU) and Battery Directive (Directive 2006/66/EC). The purpose of separating WEEE and batteries from other waste is to minimize the otential environmental impacts and human health risk of any hazardous substances that may be present.Reduction of hazardous substancesThis device is compliant with the REACH Regulation [Regulation (EC) No 1907/2006] and RoHS Directive Recast (Directive 2011/65/EU). Batteries (if included) are compliant with the Battery Directive (Directive 2006/66/EC). For up-to-date information about REACH and RoHS compliance, please visit the web site www.huaweidevice.com/certification.EU regulatory conformanceStatementDISCLAIMERALL CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL HUAWEI BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOSS OF PROFITS, BUSINESS, REVENUE, DATA, GOODWILL SAVINGS OR ANTICIPATED SAVINGS REGARDLESS OF WHETHER SUCH LOSSES ARE FORSEEABLE OR NOT. THE MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT APPLY TO LIABILITY FOR PERSONAL INJURY TO THE EXTENT APPLICABLE LAW PROHIBITS SUCH A LIMITATION) OF HUAWEI ARISING FROM THE USE OF THE PRODUCT DESCRIBED IN THIS MANUAL SHALL BE LIMITED TO THE AMOUNT PAID BY CUSTOMERS FOR THE PURCHASE OF THIS PRODUCT.Privacy PolicyPlease refer to our privacy policy on our websites for the information about how we protect your personal information. ®
