Nxcontrol System NXBEE01 NxRemote Kit User Manual

Nxcontrol System Co., Ltd. NxRemote Kit Users Manual

Users Manual

©2015 NxControl System Co, Ltd. All right reserved.All other trademarks are the property of theirrespecve owners.The use of the word partner does not imply a partnership relaonship and any other company.NxControl assures no responsibility for any errorsthat may appear in the manual.Informaon contained here in is subject to changewithout noce. 2MUUDE0002 2015.12Device TypeWireless TypeIR Code LearningInterfacePersonal Scenario SengOperang SystemColorSizes (LxWxH)WeightRemote DongleZigBee (Low Electronmagnec Wave)YesMicro USBYesAndroid 4.0 above, USB OTG SupportedBlack / White49.8 x 22.0 x 7.0 mm15gDevice TypeWireless TypeNetworking RangeIR FrequencyPowerColorSizes (RxH)WeightRF to IR AdapterZigBee (Low Electronmagnec Wave)30 m above (In door)36 KHz ~ 56 KHz3V CR2032 Lithium BaeryBlack / WhiteR13.0 x 7.3 mm10gPower Light IR Code Learning LightIR ReceiverMicro USBIR TransmierStatus LightNxRemote NxBeeTM TM11. Download APPAPPScan QR code or search “NxRemote” for downloadingAPP on Google Play.22. Plug in NxRemote 2. Plug in NxRemote. 3. When noce message shows up, make sure to check “Use by default for this USB device” to allow the app to access your USB device.(Some devices need to enable USB OTG funcon. e.g. Sony : Sengs -> Xperia Connecvity -> USB Connecvity -> Detect USB device)1. Check your Android phone / tablet supporng USBOTG funcon.List of Android Phones and Tablet supports OTG Funcon: hp://www.nxcontrol.com/OTG.phpNxRemote ConnectedA/CListenSettingsScenarioProfileWatchOthers33. Pair NxBeeSearch NxBeeAPPAPP1.Remove NxBee back cover, and pull out the baerytab. The green light will start blinking.2. From APP Homepage to Seng : Seng -> Device Setup -> click search buon.3. Select NxBee and enter pair number, it will stop blink and show up on the screen.4. Click NxBee icon. While connects withNxRemote correctly, the green light willblink. If not, please replace baery andtry again. 44. Setup & Learn IR codes1. Click seng to begin learning.2. Choose type,brand, locaon of applicances and then click learning boon.3.Click corresponding key on your original remote to learnIR code. If the countdown message disappears, the buonlearning process is completed.4. Aer learning successful, back to Homepage and start tocontrol.VOL CHOriginal Remote2 Inch IR421 3865709ONBlinkRedLearning.....10 seconds54.1 Learn A/C IR Code(OFF Buon)1. Click “ OFF” buon to beginlearning process. 2. Point your original remote at the boom of NxRemote, and click OFF key to learn the IR code.＊A/C remote must be turned “ON” before learning. OFFA/C RemoteOFF2 Inch IRBlinkRed025CLearning.....10 seconds65. Try Your NxRemote1. Press “ Home ” or “ back ” to home page, the device icons will light up.2. Press Power key on your NxRemote APP to checkif the device works.Green light will blink when you press the buon key.VOL CHA/CListenSettingsScenarioProfileWatchOthers84.2 Learn A/C IR Codes(ON Buon)OFFMODETEMPFAN SPEEDSWING70F1. Adjust the status (Temp., Mode,Fan Spd, Swing) on original remoteand NxRemote with the same status. 2. Click “ ON ” buon to begin learning process. 3. Point your original remote at the boom of NxRemote and click the power key to learn the IR code.＊A/C remote must be turned “OFF” before learning. ON2 InchIRBlinkRedLearning.....10 secondsA/C Remote7
6. Adhere NxBeeIR receiving area (Do NOT cover power light.)IR transmissiondirecon1. Place NxBee close to IR receivingarea (near power light normally) and try to click power to turn on/off.2. While applicances turn on, the IR receiving area is correct.Then , adhere NxBee near this area.97. Control Home AppliancesNxRemote Kit should only be used in environments withambient temperatures between 0°C (32°F) and 35°C (95°F)108. Scenario SetupSOURCEVOL CHSOURCEVOL CHSave Scenario?CANCELOK1. Press record buon to start up. 2. Start your control process, and click record buon againwhen you finish all acons.3. Save your acon to move on next step. 114. Choose your scenario icon and select user if alreadyhave one, check delay me for each buons,name your mode and save it.5. Back to APP Homepage , choose your favorite scenario to begin. CANCELSAVEReading ModeJohnDelay TimeJohnReading ModeMovie ModeECO ModeRelax ModeParty ModeExercise Mode14:0016:0012Warranty Informaon FormMr./Mrs./Ms./Miss: ____________________________________________________________Telephone Number: ____________________________________________________________Address: ______________________________________________________________________E-mail: ________________________________________________________________________Dealer's Name: _________________________________________________________________Dealer's Telephone Number: ________________________________________________Dealer's Address: _________________________________________________________Purchase Date : / / (DD/MM/YYYY) Chapter dealership(Chapter invalid uncapped shop)(During the warranty period with this item warranty service warranty card, please keep this warranty card, lost without replacement) 13Important Safety InformaonWhen using this product, the safety precauons below must be taken avoid possible legal liabilies and damages.Retain and follow all product safety and operaon instrucons.Observe all warnings in the operaon instrucons on the product.To reduce the risk of bodily injury, electric shock, fire and damage to the equipment. Observe the following precauons.Care Do not open NxRemote. There are no user-serviceable parts inside. Do not allow moisture to enter the unit. Moisture will corrode the inner electronics. Any changes or modificaons not expressly approved by NxControl void the user’s authority to operate the device and could void the warranty. The product should only be used in environments with ambient temperatures between 0 degree C (32 degree F) and 35 degree C (95 degree F).Handle Baery Carefully NxBee contains a lithium non-rechargeable baery. Baery life is dependent upon usage. Heavy daily use will result in shorter baery life. There is a risk of fire and burn if the baery is handle improperly. Do not disassemble, crush, puncture, short external contacts or circuits, dispose of in fire or water, or expose a baery to temperatures higher than 60 degree C (140 degree F).End-of-life Baery Disposal Instrucons If baery is end-of-life, consult local laws and regulaons for proper baery disposal in your area. If there are no local regulaons concerning baery disposal, please dispose of the dead baery in a waste bin for electronic devices. KEEP ALL BATTERIES OUT OF THE REACH OF CHILDREN.Disposal and Recycling InformaonThe symbol indicates that your product must be disposed of properly according to local laws and regulaons. When your product reaches its end of life, contact your local authories to learn about recycling opons.European Union – Disposal InformaonThe symbol above means that according to local laws and regulaons your product and/or its baery shall be disposed of separately from household waste. When this product reaches its end of like, take it to a collecon point designated by local authories. The separate collecon and recycling of your product and/or it baery at the me of disposal will help conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment.Safety Precauon for Small Children Do not leave your product within the reach of small children or allow them to play with it. They could hurt themselves or others, or could accidentally damage the product. Your product contains small parts with sharp edges that may cause an injury or which could become detached and create choking hazard. Consult the doctor immediately if the accessories or baery are swallowed. Do not disassemble it or aempt to recharge it outside the system. Do not crush, puncture, dispose of in fi re, short the external contacts, or expose to water or other liquids. Dispose of the baery in accordance with local regulaons and instrucons from your service provider.14Limited Warranty StatementThe Limited Warranty Statement is a voluntary manufacturer's warranty. It provides rights separate to rights provided by consumer law, including but not limited to those relang to non-conforming goods. As such, the Limited Warranty Statement benefits are in addion to, and not instead of, rights provided by consumer law.Your hardware product is warranted against defects in materials and workmanship for a period of ONE (1) YEAR from the date of original retail purchase ("Warranty Period"). If a defect arises during the Warranty Period, NxControl, at its opon and to the extent permied by law will (1) repair the product at no charge using new parts or parts that are equivalent to new in performance and reliability, or (2) exchange the product with a funconally equivalent product that is new or equivalent to new in performance and reliability. This warranty excludes damage resulng from abuse, accident, modificaons or other causes that are not defects in materials and workmanship.Other than the consumer law rights to which you are entled, all warranes, condions and other terms not set out in this warranty document are excluded from the Limited Warranty Statement. Some countries do not allow limitaons on how long such warranes, condions and / or implied terms may last, so the limitaon described above may not apply to you. NxControl does not warrant, represent or undertake that it will be able to repair or replace any NxControl Product under this warranty without risk to and / or loss of informaon and / or data stored on the NxControl Product. In no event shall NxControl be liable for (a) any losses that were not caused by our breach of this warranty document; (b) any loss or damage that was not, at the me of your purchase of the product, a reasonably foreseeable consequence of NxControl breaching this warranty document; or (c) losses relang to any business of yours, loss of profits, loss of data or loss of opportunity. The provisions of this warranty document shall not apply to (i) death or personal injury, (ii) fraud or gross negligence; or (iii) fraudulent misrepresentaon; or (iv) any other liability that cannot be limited or excluded as a maer of law.Some countries do not allow limitaons on how long an implied warranty lasts, or allow exclusion or limitaon of incidental or consequenal damages, so the above limitaons or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights, which vary from country to country. Proof of purchase may be required to verify eligibility. For more informaon and contact support, please refer to NxControl webpage at hp://www.nxcontrol.com 16Cerficaon and ComplianceU.S. FCC ID:2AGNZ-NXREMOTE01 / 2AGNZ-NXBEE01Canada IC:20895-NXREMOTE01 / 20895-NXBEE01EU AustraliaNew Zealand TaiwanJapan FCC Radiaon Exposure Statement (FCC ID: 2AGNZ-NXBEE01)This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.Canada Compliance StatementThis device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions:(1)This device may not cause interference; and (2)This device must accept any interference, including interference that may cause undesired operation of the device.Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.IMPORTANT NOTE:IC Radiation Exposure Statement(IC: 20895-NXBEE01):This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non contrôlé.CAN ICES-3 (B)/NMB-3(B)CCAF15LP2340T0T CCAF15LP2350T315R123-456789R123-456789
