Otodata Wireless Network C005 Wireless Alarm Communicator User Manual CONFIDENTIAL AND PROPRIETARY

Otodata Wireless Network Inc. Wireless Alarm Communicator CONFIDENTIAL AND PROPRIETARY

User Manual

CONFIDENTIAL & PROPRIETARY C005 v.0r1 ModemThe C005 modem is an autonomous transceiver that is used primarily for the communication of identification, control and management information using RF (radio frequencies). The modem may be used in conjunction with active transponders which may be affixed to assets with which it can communicate in order to collect data. System description. The C005 system has been developed with the goal of providing the following services. Data transfer, logging and TelemetryTemperature monitoringHumidity monitoringAutomated inventory managementAutomated fleet managementStolen vehicle trackingAlarm signal communication (CID)The use of the C005 enables automated and remote data collection. It also offers the ability to control and monitor the property on which our proprietary transceivers are affixed. This monitoring and control is done according to schedules and specific conditions that have been previously established. The modem operates using a communication protocol that is both highly secure and robust. It contains a proprietary information recovery and patterning encoding. The C005 was developed in order to minimize the use of space while also minimizing its visibility. This equipment was also developed so that it can operate with great efficiency, thus providing greater autonomy in emergency situations. One of the main criteria for the development was reduced operating cost. This is achieved by virtue of the fact that energy consumption is kept to a minimum by maximizing overall system efficiency. This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Please note: The minimum separation distance between the device's antenna and all persons during normal operation is 25 centimeters. Warning: Any changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. Do not attempt to tamper or make any changes to this device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. SPRS ReadySelf-containedExtended service lifeHighly robust communicationprotocolUSER MANUAL
Avertissement RF conformité de l’exposition. L’antenne (s) utilisée pour cet émetteur doit être installée pour fournir une distance de séparation d’au moins 25cm de toutes personnes et ne doit pas être situé à proximité ou fonctionner en conjonction avec une autre antenne ou émetteur. Tout changement ou modification non expressément approuvé par la partie responsable de la conformité risque d’invalider l’autorisation accordée à l’utilisateur d’utiliser cet appareil. Les utilisateurs et les installateurs doivent recevoir des instructions d’installation de l’antenne et des conditions de fonctionnement du transmetteur satisfaisant le respect de l’exposition aux RF. Caracteristics Advantages Benefits Rugged reinforced enclosure The enclosure is madeof molded high density andreinforced fiberglass material.The enclosure is extremely solid andresistant thus guaranteeing durable protection. The enclosure is also built to withstand elevated temperatures. Autonomous and automated operation Our system is the only electronicsystem for automated identificationand management that can operateautonomously.Remote and autonomous operationhelps to reduce overall operating and maintenance costs. Active LR (RFID) This system offers the possibility ofremotely identifying data in an automated and secure fashion. Remote and secure data identificationand collection provides anindependent and covert data flow.Secure and robust communication protocol The RF environment is more andmore saturated, hence the need for robust communication means. Data is transmitted using an encodingsystem that maintains a very highdegree of data integrity. It is thereforepossible to recover data even inextreme circumstances.Technical specifications General information Operational & Environmental Outside dimensions (Enclosure) Operating temp. : -40 +85°C Height : 44.45 mm (1.75 inches) Environmental protection : IP6x (non-immersed) Width : 190.50 mm (7.50 inches) Length : 127.00 mm (5.00 inches) Specifications ( TX / RX ) Material : Molded reinforced fiberglass Color : Light-grey / Beige Receiver Antenna : Rubber duck 1/4 Span (freq.) : 902.000MHz ~ 928.000MHz Modulation : SSFH / 2FSK Sensitivity: -114 dBm Battery Transmitter Type : LisoC Primary (no maintenance) Span (freq.) : 902.000MHz ~ 928.000MHz Chemistry : Lithium Thyonil Chloride Modulation : FH / 2FSK Charge time : Non-Rechargeable Encoding : Variable encoding Capacity-Voltage : 10Ah ~ 14.75Vdc Output power : 30 dbm Electrical Supply voltage (lead in) : N/A (Internal sealed bat pack) Internal voltage: 3.3Vdc Electrical consumption: Variable. Peak 0.05% Certifications Industry Canada RSS-247 Issue1 FCC (United-States) Part 15 (C) The information contained in this document may be changed or modified without notice. This information remains the sole and exclusive property of Otodata Wireless Network Inc.
